Marsriva MR-SPF5K-LP1-TL20E 5kW Hybrid Solar Inverter
Contact us for pricing
Product Details
Key Features
High Power Output: Delivers a rated output of 5kW with 5kVA capacity, suitable for demanding applications.
Wide Input Voltage Range: Accepts 208/220/230/240VAC nominal with 170–264VAC UPS and 90–280VAC APP mode ranges.
Fast Transfer Time: Transfers power in 10ms for UPS/APP and 20ms for GEN mode, ensuring seamless operation.
Dual Battery Compatibility: Supports lead‑acid, lithium, or user‑defined batteries at 24VDC nominal.
Robust Solar Integration: MPPT charger handles up to 9000W PV input, 27A current, and 500VDC open circuit voltage.
High Efficiency Battery Mode: Achieves up to 93.5% efficiency in battery mode for optimal energy use.
Compact Footprint: Dimensions 336×410×110mm and 8.4kg weight make it easy to install in tight spaces.
Advanced Communication: Includes BMS(485/CAN) and WiFi for remote monitoring and management.
Wide Temperature Tolerance: Operates from -10°C to 50°C and stores from -15°C to 60°C for harsh environments.
Surge Protection: Provides surge power at twice the rated output to safeguard connected equipment.
Model | MR-SPF5K-LP1-TL20E |
Rated Power | 5kVA / 5kW |
Input Nominal Voltage | 208 / 220 / 230 / 240VAC |
Voltage Range | 170 – 264VAC (UPS Mode); 90 – 280VAC (APP Mode) |
Frequency Range | 50 / 60Hz ±10Hz (Auto sensing) |
Output Nominal Output Voltage | 208 / 220 / 230 / 240VAC ± 5% |
Output Power Rated | 5kW; 4kW(Only Battery) |
Surge Power | 2 times of rated power |
Nominal Output Frequency | 50 / 60Hz ± 0.1% (Batt. Mode) |
Efficiency | Max. 93.5% (Batt. Mode) |
Transfer Time | 10ms (UPS/APP Mode); 20ms (GEN Mode) |
Battery Nominal Voltage | 24VDC |
Battery Voltage Range | 20VDC – 30.5VDC |
Battery Type | Lead-acid / Lithium / User-defined |
Solar Charger Type | MPPT |
Max. PV Input Power | 9000W |
Max. PV Input Current | 27A |
PPT Voltage Range | 60 – 450VDC (Min. 80VDC without battery connected) |
Max. PV Open Circuit Voltage | 500VDC |
Max. Solar Charging Current | 160A |
Max. AC Charging Current | 160A |
Max. Hybrid Charging Current | 160A |
Dimension (W x H x D) | 336 × 410 × 110 mm |
Net Weight | 8.4 kg |
Communication Interface | BMS(485/CAN), WiFi Module |
Humidity | 5% to 95% Relative Humidity (Non-condensing) |
Operating Temperature | -10°C to 50°C |
Storage Temperature | -15°C to 60°C |
Description
Marsriva MR-SPF5K-LP1-TL20E 5kW Hybrid Solar Inverter
Key Features & Benefits:
- High Power Output: Delivers a rated output of 5kW with 5kVA capacity, suitable for demanding applications.
- Wide Input Voltage Range: Accepts 208/220/230/240VAC nominal with 170–264VAC UPS and 90–280VAC APP mode ranges.
- Fast Transfer Time: Transfers power in 10ms for UPS/APP and 20ms for GEN mode, ensuring seamless operation.
- Dual Battery Compatibility: Supports lead‑acid, lithium, or user‑defined batteries at 24VDC nominal.
- Robust Solar Integration: MPPT charger handles up to 9000W PV input, 27A current, and 500VDC open circuit voltage.
- High Efficiency Battery Mode: Achieves up to 93.5% efficiency in battery mode for optimal energy use.
- Compact Footprint: Dimensions 336×410×110mm and 8.4kg weight make it easy to install in tight spaces.
- Advanced Communication: Includes BMS(485/CAN) and WiFi for remote monitoring and management.
- Wide Temperature Tolerance: Operates from -10°C to 50°C and stores from -15°C to 60°C for harsh environments.
- Surge Protection: Provides surge power at twice the rated output to safeguard connected equipment.
Ideal For:
- Commercial solar farms needing high‑capacity hybrid inverters
- Residential off‑grid homes with battery backup
- Industrial facilities requiring UPS and generator support
- Renewable energy projects with large PV arrays
- Utility‑scale microgrid operators
- Remote telecom sites with hybrid power needs
- Agricultural operations needing reliable backup power
Summary:
The Marsriva MR‑SPF5K‑LP1‑TL20E is a 5kW hybrid solar inverter that combines high power output with versatile input voltage and frequency ranges. Its MPPT solar charging, fast transfer times, and 93.5% battery‑mode efficiency make it ideal for commercial, industrial, and residential hybrid systems. With robust battery support, wide temperature tolerance, and advanced communication, it is a reliable choice for Bangladesh’s growing renewable market. Available now at Revolution Technology BD.
