Marsriva MR-SPF12K-LP1-TL20E 12kW Hybrid Solar Inveter
Contact us for pricing
Product Details
Key Features
High Power Output: Delivers 12kVA / 12kWAC peak power with a surge capability of 24kVA, ideal for heavy appliances.
Fast Transfer Time: UPS transfer time of 10ms for PCs and 20ms for home appliances ensures zero downtime.
Dual Output Flexibility: Provides both AC and 12VDC outputs (100W) for versatile device support.
Pure Sine Wave Inverter: Produces clean, pure sine wave output for sensitive electronics.
Smart Load Management: Dual outputs and RGB status lights enable intelligent load distribution.
Remote Monitoring: Built‑in Wi‑Fi and mobile app allow real‑time status tracking from anywhere.
Solar and Grid Compatibility: Supports up to 500VDC PV input and 200A grid input for hybrid power solutions.
Easy Maintenance: Replaceable fan design and anti‑dust kit simplify upkeep.
Parallel Operation: Can operate in parallel with up to 6 units to scale capacity.
Battery Independence: Designed to work with lead‑acid, lithium, or user‑defined batteries.
Battery Type | Lead‑acid / Lithium / User‑defined |
Rated AC Output Power | 12kVA / 12kWAC Peak/ Surge Output Power |
UPS Transfer Time | 10ms (For PC); 20ms (For Home Appliances) |
Connectivity | USB, RS232, BMS(485,CAN), WiFi Module, Dry‑contact Protection 63VDC Overcharge Protection |
Dual outputs for smart load management | Yes |
Status indication with RGB lights | Yes |
Built‑in Wi‑Fi for mobile monitoring (Android/iOS App available) | Yes |
Supports USB On‑the‑Go function | Yes |
Replaceable fan design for ease of maintenance | Yes |
Battery independent design | Yes |
Selectable high power charging current | Yes |
Compatible to Utility Mains or generator input | Yes |
Built‑in anti‑dust kit | Yes |
Optional DC output for DC fan, LED bulb and so on | Yes |
Parallel operation with 6 units | Yes |
AC Output | 230VAC ± 5% |
Nominal Output Frequency | 50Hz / 60Hz |
DC Output | 12VDC ± 5%, 100W |
Output Waveform | Pure sine wave |
Surge Power | 2 times of rated power |
Peak Efficiency | 95% at Line mode, 93% at Inverter mode |
Input (Charging) AC Input | 230VAC (Nominal) 170 – 280VAC (For PC); 90 – 280VAC (For Home Appliances) (Selectable) |
Solar Input Max. PV Array Open Circuit Voltage | 500VDC |
Solar Input Max. PV Input Current | 27A*2 (MAX. 45A) |
Grid/ Wall Input | 200A |
Dimension | 147.4 × 432.5 × 553.6mm (W x H x D) |
Weight | 18.4 kg |
Description
Marsriva MR-SPF12K-LP1-TL20E 12kW Hybrid Solar Inveter
Key Features & Benefits:
- High Power Output: Delivers 12kVA / 12kWAC peak power with a surge capability of 24kVA, ideal for heavy appliances.
- Fast Transfer Time: UPS transfer time of 10ms for PCs and 20ms for home appliances ensures zero downtime.
- Dual Output Flexibility: Provides both AC and 12VDC outputs (100W) for versatile device support.
- Pure Sine Wave Inverter: Produces clean, pure sine wave output for sensitive electronics.
- Smart Load Management: Dual outputs and RGB status lights enable intelligent load distribution.
- Remote Monitoring: Built‑in Wi‑Fi and mobile app allow real‑time status tracking from anywhere.
- Solar and Grid Compatibility: Supports up to 500VDC PV input and 200A grid input for hybrid power solutions.
- Easy Maintenance: Replaceable fan design and anti‑dust kit simplify upkeep.
- Parallel Operation: Can operate in parallel with up to 6 units to scale capacity.
- Battery Independence: Designed to work with lead‑acid, lithium, or user‑defined batteries.
Ideal For:
- Small business owners needing reliable backup power
- Home users with sensitive electronics like computers
- Solar‑powered homes requiring hybrid solutions
- Data centers requiring fast transfer times
- Industrial equipment operators needing clean power
- Remote offices with limited grid access
- Home automation enthusiasts
Summary:
The Marsriva MR‑SPF12K‑LP1‑TL20E 12kW Hybrid Solar Inverter is a robust power solution that delivers 12kVA/12kW AC output with a surge capacity of 24kVA and a 10ms transfer time for PCs. Its dual AC/DC outputs, pure sine wave, and Wi‑Fi monitoring make it ideal for homes, small businesses, and solar‑integrated setups. Available at Revolution Technology BD, this inverter supports lead‑acid, lithium, or user‑defined batteries and can be expanded by parallel operation with up to six units.
