Marsriva MR-SPF2K-LP1-TL20E 2kW Hybrid Solar Inveter
Contact us for pricing
Product Details
Key Features
Dual‑Mode Power: Supports both battery and grid input, ensuring uninterrupted power with a 10ms transfer time.
High Power Output: Delivers 2kW AC peak power with a 2× surge capability for heavy loads.
Wide Input Range: Accepts 30–400V AC input and up to 3000W solar input for flexible installation.
Pure Sine Wave: Provides clean 208/220/230/240VAC ±5% output for sensitive electronics.
Compact Design: Only 331×270×100mm and 4.5kg, ideal for tight spaces.
MPPT Solar Charging: Maximum Power Point Tracking up to 3000W and 450V DC for efficient solar use.
IP20 Protection: Dust‑proof and safe for indoor environments.
Fast Transfer: 10ms UPS transfer ensures zero downtime during power source change.
Grid Feed‑In: Can export surplus solar power back to the grid.
Wide Temperature Range: Operates from -10°C to 60°C, suitable for varied climates.
Battery Flexibility: Compatible with lead‑acid, lithium, or user‑defined batteries.
Lightweight: At 4.5kg, easy to install on rooftops or inverters cabinets.
Battery Type | Lead‑acid / Lithium / User‑defined |
Rated AC Output Power | 2kVA / 2kW AC Peak/ Surge Output Power 2 times of rated power |
UPS Transfer Time | 10ms (UPS/APP/GEN Mode) |
Connectivity | RS485 / CAN / RS232 |
Protection | IP20 Protection |
Others | High frequency inverter with small size and light weight Solar and utility grid can power loads at the same time With the ability to work without battery Feed‑in to grid function |
Output AC Output | 208 / 220 / 230 / 240VAC ± 5% |
Nominal Output Frequency | 50 / 60Hz ± 0.1% (Batt. Mode) |
Output Waveform | Pure sine wave AC output |
Input (Charging) AC Input | 30 – 400V DC (Min. 60V DC without battery connected) |
Solar Input | Solar Charger Type: MPPT Max. PV Input Power: 3000W Max. PV Input Current: 18A Max. PV Open Circuit Voltage: 450V DC Max. Solar Charging Current: 100A |
Grid/ Wall Input | 100A |
Environment Operating Temperature | -10°C to 60°C |
Storage Temperature | -15°C to 60°C |
Physical Information | Dimension 331 × 270 × 100mm (W x H x D) Weight 4.5kg |
Description
Marsriva MR-SPF2K-LP1-TL20E 2kW Hybrid Solar Inveter
Key Features & Benefits:
- Dual‑Mode Power: Supports both battery and grid input, ensuring uninterrupted power with a 10ms transfer time.
- High Power Output: Delivers 2kW AC peak power with a 2× surge capability for heavy loads.
- Wide Input Range: Accepts 30–400V AC input and up to 3000W solar input for flexible installation.
- Pure Sine Wave: Provides clean 208/220/230/240VAC ±5% output for sensitive electronics.
- Compact Design: Only 331×270×100mm and 4.5kg, ideal for tight spaces.
- MPPT Solar Charging: Maximum Power Point Tracking up to 3000W and 450V DC for efficient solar use.
- IP20 Protection: Dust‑proof and safe for indoor environments.
- Fast Transfer: 10ms UPS transfer ensures zero downtime during power source change.
- Grid Feed‑In: Can export surplus solar power back to the grid.
- Wide Temperature Range: Operates from -10°C to 60°C, suitable for varied climates.
- Battery Flexibility: Compatible with lead‑acid, lithium, or user‑defined batteries.
- Lightweight: At 4.5kg, easy to install on rooftops or inverters cabinets.
Ideal For:
- Small businesses needing backup power
- Solar‑grid hybrid installations
- Residential solar systems
- Portable power solutions
- Industrial equipment requiring clean power
- Off‑grid cabins
- Emergency power backups
Summary:
The Marsriva MR‑SPF2K‑LP1‑TL20E 2kW Hybrid Solar Inverter delivers 2kW peak AC power with a 2× surge capability, making it suitable for both residential and commercial use. Its MPPT solar input supports up to 3000W, while the 10ms transfer time ensures seamless switching between battery, solar, and grid sources. Compact, lightweight, and operating from -10°C to 60°C, it is ideal for a wide range of installations. Available now at Revolution Technology BD.
