Marsriva MR-SPF6.5K-LP1-TL54E 6.5kW Hybrid Solar Inveter
Contact us for pricing
Product Details
Key Features
High Power Output: Delivers 6.5kW AC power with a surge capacity of twice the rated power, ideal for demanding applications.
Fast UPS Transfer: Transfers power in 10ms (UPS/APP Mode) or 20ms (GEN Mode), ensuring seamless load protection.
Dual AC Output: Supports multiple AC outputs (208/220/230/240VAC) with ±5% tolerance for versatile connectivity.
Pure Sine Wave: Provides clean, pure sine wave AC output for sensitive electronics and appliances.
MPPT Solar Charging: Maxes solar efficiency with an MPPT charger handling up to 9000W PV input and 120A charging current.
Compact Design: Small footprint (336×410×110mm) and lightweight (10kg) for easy installation.
Robust Connectivity: Includes BMS 485/CAN and WiFi for real-time monitoring and remote management.
IP20 Protection: Offers basic protection against dust and splashes, suitable for indoor use.
Wide Operating Range: Operates from -10°C to 50°C, with storage up to -15°C to 60°C for flexible deployment.
Grid Feed-in Capability: Allows feeding excess power back to the grid, optimizing energy usage.
Battery Type | Lead-acid / Lithium / User-defined |
Rated AC Output Power | 6.5kVA / 6.5kWAC Peak/ Surge Output Power 2 times of rated power |
UPS Transfer Time | 10ms (UPS/APP Mode); 20ms (GEN Mode) |
Connectivity | BMS(485/CAN), WiFi Module |
Protection | IP20 Protection |
Others | High frequency inverter with small size and light weightSolar and utility grid can power loads at the same timeWith the ability to work without batteryDual AC outputFeed-in to grid function |
Output AC Output | 208 / 220 / 230 / 240VAC ± 5% |
Nominal Output Frequency | 50 / 60Hz ± 0.1% (Batt. Mode) |
Output Waveform | Pure sine wave AC output |
Input (Charging) AC Input | 60 – 450VDC (Min. 80VDC without battery connected) |
Solar Input Solar Charger Type | MPPT |
Max. PV Input Power | 9000W |
Max. PV Input Current | 27A |
Max. PV Open Circuit Voltage | 500VDC |
Max. Solar Charging Current | 120A |
Grid/ Wall Input | 120A |
Operating Temperature | -10°C to 50°C |
Storage Temperature | -15°C to 60°C |
Dimension | 336 × 410 × 110mm (W x H x D) |
Weight | 10 kg |
Description
Marsriva MR-SPF6.5K-LP1-TL54E 6.5kW Hybrid Solar Inveter
Key Features & Benefits:
- High Power Output: Delivers 6.5kW AC power with a surge capacity of twice the rated power, ideal for demanding applications.
- Fast UPS Transfer: Transfers power in 10ms (UPS/APP Mode) or 20ms (GEN Mode), ensuring seamless load protection.
- Dual AC Output: Supports multiple AC outputs (208/220/230/240VAC) with ±5% tolerance for versatile connectivity.
- Pure Sine Wave: Provides clean, pure sine wave AC output for sensitive electronics and appliances.
- MPPT Solar Charging: Maxes solar efficiency with an MPPT charger handling up to 9000W PV input and 120A charging current.
- Compact Design: Small footprint (336×410×110mm) and lightweight (10kg) for easy installation.
- Robust Connectivity: Includes BMS 485/CAN and WiFi for real-time monitoring and remote management.
- IP20 Protection: Offers basic protection against dust and splashes, suitable for indoor use.
- Wide Operating Range: Operates from -10°C to 50°C, with storage up to -15°C to 60°C for flexible deployment.
- Grid Feed-in Capability: Allows feeding excess power back to the grid, optimizing energy usage.
Ideal For:
- Residential solar systems with battery backup
- Commercial HVAC and lighting loads
- Off-grid remote facilities
- Data centers requiring uninterrupted power
- Industrial machinery with high surge demands
Summary:
The Marsriva MR-SPF6.5K-LP1-TL54E is a 6.5kW hybrid solar inverter that delivers high power, fast UPS transfer, and pure sine wave output. Its MPPT solar charging, dual AC outputs, and compact design make it suitable for residential, commercial, and industrial applications. Available at Revolution Technology BD, it offers robust connectivity and wide operating temperature ranges for reliable performance.
