Supermicro SYS-420GP-TNR 4U GPU Server

Genuine Product Fast Delivery Easy Returns

Key Features

Dual-CPU High Core Count: Equipped with dual Socket P+ (LGA-4189) 3rd Gen Intel Xeon Scalable processors delivering up to 40 cores per socket for massive parallel workloads.

Massive GPU Flexibility: Supports up to 10 GPUs, including NVIDIA H100, A100, A30, RTX A6000, and Intel Data Center GPU Flex 170, ideal for AI, HPC, and graphics rendering.

Extensive Memory Capacity: 32 DIMM slots with up to 8TB ECC DDR4 3200MT/s, plus Intel Optane persistent memory, ensuring high throughput and reliability.

Robust Storage Options: SATA 6Gbps with RAID 0/1/5/10 support provides flexible, high-performance storage configurations.

Enterprise Networking: Dual 1GbE ports via Intel I350 NICs for resilient, low-latency connectivity.

Advanced Management Suite: SuperCloud Composer, SSM, SUM, SD5, SDO, TAS, and SAA provide comprehensive server lifecycle and automation management.

Secure Boot & Firmware Integrity: TPM 2.0, Silicon Root of Trust, cryptographically signed firmware, and automatic firmware recovery protect against tampering.

Comprehensive Thermal & Power Monitoring: Phase-switching voltage regulator, fan tachometers, PWM connectors, and temperature sensors maintain optimal operating conditions.

Wide OS Compatibility: Certified for ESXi, Hypervisor, Oracle Linux, RHEL, and Windows Server, enabling versatile virtualization and application deployment.

Scalable Power Management: AC power recovery and ACPI Power Management ensure reliable uptime and energy efficiency.

Specification

Product SKUs	SYS-420GP-TNR
Motherboard	Super X12DPG-OA6
Processor CPU	Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors
Core Count	Up to 40C/80T
Cache per CPU	Up to 60MB
CPU TDP Support	Up to 270W (Air Cooled)
Max GPU Count	Up to 10 double-width or 10 single-width GPUs
Supported GPUs	NVIDIA PCIe: H100, A10, A100, A16, A2, A30, A40, L40, RTX A2000, RTX A4000, RTX A4500, RTX A5000, RTX A5500, RTX A6000; Intel PCIe: Intel Data Center GPU Flex 170
GPU Options	View GPU Options
CPU-GPU Interconnect	PCIe 4.0 x16 Switch Dual-Root
GPU-GPU Interconnect	NVIDIA® NVLink™ Bridge (optional)
System Memory Slot Count	32 DIMM slots
Max Memory (2DPC)	Up to 8TB 3200MT/s ECC DDR4 RDIMM/LRDIMM
Optane Support	Intel® Optane™ persistent memory 200 series
Memory Voltage	1.2V
On-Board Devices	SATA (6Gbps); RAID 0/1/5/10 support
Network Connectivity	2 RJ45 1GbE with Intel® I350
AOC Options	View AOC Options
BMC	ASPEED AST2600 BMC
Video	VGA port
System BIOS	AMI 32MB SPI Flash EEPROM
Management Software	SuperCloud Composer® (SCC), Supermicro Server Manager (SSM), Supermicro Update Manager (SUM), Supermicro SuperDoctor® 5 (SD5), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA)
Power Configurations	Power-on mode for AC power recovery, ACPI Power Management
Security	Trusted Platform Module (TPM) 2.0, Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Cryptographic Features	Cryptographically Signed Firmware, Secure Boot, Secure Firmware Updates, Automatic Firmware Recovery
System Lockdown	PC Health Monitoring
CPU Power Regulation	7 +1 Phase-switching voltage regulator
CPU Core Monitoring	Monitors for CPU Cores, Chipset Voltages, Memory
Fan Monitoring	Fans with tachometer monitoring, Pulse Width Modulated (PWM) fan connectors, Status monitor for speed control
Temperature Monitoring	Temperature Monitoring for CPU and chassis environment
Thermal Control	Thermal Control for fan connectors
Operating Systems	ESXi 6.7 U3, ESXi 7.0 U2, Hypervisor 8.2, Oracle Linux 8.3, RHEL 7.9, RHEL 8.3, RHEL 9.0, Windows Server 2019, Windows Server 2022

Description

Supermicro SYS-420GP-TNAR 4U 8-GPU Server

Key Features & Benefits:

Dual-CPU High Core Count: Equipped with dual Socket P+ (LGA-4189) 3rd Gen Intel Xeon Scalable processors delivering up to 40 cores per socket for massive parallel workloads.
Massive GPU Flexibility: Supports up to 10 GPUs, including NVIDIA H100, A100, A30, RTX A6000, and Intel Data Center GPU Flex 170, ideal for AI, HPC, and graphics rendering.
Extensive Memory Capacity: 32 DIMM slots with up to 8TB ECC DDR4 3200MT/s, plus Intel Optane persistent memory, ensuring high throughput and reliability.
Robust Storage Options: SATA 6Gbps with RAID 0/1/5/10 support provides flexible, high-performance storage configurations.
Enterprise Networking: Dual 1GbE ports via Intel I350 NICs for resilient, low-latency connectivity.
Advanced Management Suite: SuperCloud Composer, SSM, SUM, SD5, SDO, TAS, and SAA provide comprehensive server lifecycle and automation management.
Secure Boot & Firmware Integrity: TPM 2.0, Silicon Root of Trust, cryptographically signed firmware, and automatic firmware recovery protect against tampering.
Comprehensive Thermal & Power Monitoring: Phase-switching voltage regulator, fan tachometers, PWM connectors, and temperature sensors maintain optimal operating conditions.
Wide OS Compatibility: Certified for ESXi, Hypervisor, Oracle Linux, RHEL, and Windows Server, enabling versatile virtualization and application deployment.
Scalable Power Management: AC power recovery and ACPI Power Management ensure reliable uptime and energy efficiency.

Ideal For:

AI & Machine Learning researchers
High-Performance Computing clusters
GPU-accelerated graphics studios
Data center virtualization hosts
Enterprise database servers
Scientific simulation labs
Edge AI deployment hubs

Summary:

The Supermicro SYS-420GP-TNAR 4U 8-GPU Server is a powerhouse designed for demanding AI, HPC, and virtualization workloads. With dual 3rd Gen Intel Xeon Scalable CPUs, up to 8TB of ECC DDR4 memory, and support for ten high‑end GPUs, it delivers unmatched performance and scalability. Its comprehensive management suite, secure firmware, and robust networking make it ideal for enterprise data centers and research facilities. Available now at Revolution Technology BD, this server offers a turnkey solution for cutting‑edge computing needs.
