Dahua S3006-4ET-36 6-Port Unmanaged Desktop Switch with 4-Port PoE
Contact us for pricing
Product Details
Key Features
Easy Installation: The switch comes with a desktop mount and wall mount for easy installation.
High-Speed Performance: With a switching capacity of 1.2 Gbps, this switch provides high-speed performance for your network.
Power over Ethernet (PoE): The switch supports PoE, allowing you to power devices over Ethernet cables, reducing the need for separate power cords.
Long Distance PoE Transmission: The switch supports long distance PoE transmission, allowing you to power devices up to 250 meters away.
Durable and Reliable: The switch is made of high-quality sheet metal and has a operating temperature range of -10°C to 55°C.
Easy Management: The switch has a simple and intuitive interface, making it easy to manage and configure.
High-Power PoE: The switch supports high-power PoE, with a maximum power of 36W per port.
Wide Range of Certifications: The switch has a wide range of certifications, including CE, ensuring compliance with international standards.
Compact Design: The switch has a compact design, making it perfect for small spaces and desktop installations.
High-Speed Networking: The switch supports high-speed networking, with a packet forwarding rate of 0.893 Mpps.
Easy Maintenance: The switch has a simple and intuitive interface, making it easy to maintain and troubleshoot.
High-Quality Components: The switch is made of high-quality components, ensuring reliable and durable performance.
Wide Range of Applications: The switch is suitable for a wide range of applications, including small offices, home networks, and IoT devices.
Layer | Unmanaged |
Switching Capacity | 1.2 Gbps |
Packet Forwarding Rate | 0.893 Mpps |
Description of Function Slots | Port 1-4: 4 × RJ45 10/100 Mbps (PoE), Port 5-6: 2 × RJ45 10/100 Mbps (Uplink) |
Operating Temperature | -10 °C to +55 °C (+14 °F to +131 °F) |
Operating Humidity | 10%–90% (RH), non-condensing |
Storage Temperature | -40 °C to +75 °C (–40 °F to +167 °F) |
Storage Humidity | 5%–95% (RH), non-condensing |
Power Supply | External power supply: 53 V, 50/60 Hz, max 0.8 A |
Power Consumption | Idling: 1.3 W, Full load: 38.3 W |
Statics Protection | Air discharge: 8 kV, Contact discharge: 6 kV |
Lightning Protection | Common mode: 6 kV, Differential mode: 1 kV |
Net Weight | 0.19 kg (0.42 lb) |
Gross Weight | 0.635 kg (1.40 lb) |
Product Dimensions | 115.5 mm × 84.3 mm × 27 mm (4.55" × 3.32" × 1.06") (L × W × H) |
Packaging Dimensions | 196 mm × 115 mm × 85 mm (7.72" × 4.53" × 3.35") (L × W × H) |
Casing Material | Sheet Metal |
Installation | Desktop mount; wall mount |
Certifications | CE |
PoE | Yes |
PoE Power | Port 1-4≤30 W, total≤36 W |
PoE Protocol | IEEE 802.3af; IEEE 802.3at |
PoE Pin Assignment | 1,2,4,5 (V+),3,6,7,8 (V-) |
Long Distance PoE Transmission | Yes |
Hardware | DIP Switch |
Performance | Packet Buffer Size: 768 Kbit, Jumbo Frame: 2048 Byte, MAC Table Size: 2K |
Communication Standard | IEEE 802.3; IEEE 802.3u; IEEE 802.3x |
Packing List | 1 × User Manual, 1 × Legal and Regulatory Information, 1 × Power Cord, 1 × Power Adapter |
Description
Dahua S3006-4ET-36 6-Port Unmanaged Desktop Switch with 4-Port PoE
Key Features & Benefits:
- Easy Installation: The switch comes with a desktop mount and wall mount for easy installation.
- High-Speed Performance: With a switching capacity of 1.2 Gbps, this switch provides high-speed performance for your network.
- Power over Ethernet (PoE): The switch supports PoE, allowing you to power devices over Ethernet cables, reducing the need for separate power cords.
- Long Distance PoE Transmission: The switch supports long distance PoE transmission, allowing you to power devices up to 250 meters away.
- Durable and Reliable: The switch is made of high-quality sheet metal and has a operating temperature range of -10°C to 55°C.
- Easy Management: The switch has a simple and intuitive interface, making it easy to manage and configure.
- High-Power PoE: The switch supports high-power PoE, with a maximum power of 36W per port.
- Wide Range of Certifications: The switch has a wide range of certifications, including CE, ensuring compliance with international standards.
- Compact Design: The switch has a compact design, making it perfect for small spaces and desktop installations.
- High-Speed Networking: The switch supports high-speed networking, with a packet forwarding rate of 0.893 Mpps.
- Easy Maintenance: The switch has a simple and intuitive interface, making it easy to maintain and troubleshoot.
- High-Quality Components: The switch is made of high-quality components, ensuring reliable and durable performance.
- Wide Range of Applications: The switch is suitable for a wide range of applications, including small offices, home networks, and IoT devices.
Ideal For:
- Small office networks
- Home networks
- IoT device installations
- Point of Sale (POS) systems
- Security cameras
- Access control systems
- Voice over IP (VoIP) systems
Summary:
The Dahua S3006-4ET-36 is a 6-port unmanaged desktop switch with 4 ports supporting Power over Ethernet (PoE). It has a switching capacity of 1.2 Gbps and supports long distance PoE transmission up to 250 meters. The switch is made of high-quality sheet metal and has a compact design, making it perfect for small spaces and desktop installations. It is suitable for a wide range of applications, including small office networks, home networks, and IoT device installations. The switch is available at Revolution Technology BD.
