Artive ATL-11D286 Interactive Flat Panel 86 Inch

৳ 350,000

Exclusive of all taxes

Genuine Product Fast Delivery Easy Returns

Specification

Processor	A734 + A534 (4 Core+4 Core) 2.28GHz
Memory Size	8GB
Memory Type	DDR4
ROM	128GB
Screen Size	86″ LED Backlight
Image	Support JPG/JPEG/BMP/PNG and other image formats
Resolution	3840*2160 /60hz
Brightness	350cd/m²
Aspect Ratio	16:09
Response Time	<8 ms
Viewing Angle	178°
Contrast	1200:1 (Typ.)
Color Support	1.07 Billion Colors
Graphics	G52 MP8
Camera	Built-in 48 Million Wide-Angle Auto-Framing & Sound-Tracking Camera
Wi-Fi	Wi-Fi 6 (2.4G+5G) Dual Band
Bluetooth	5
Audio	Support MPEG1/2、AC3、EAC3(DDP)、AAC、HEAAC、WMA、WMA10 pro
Mic	8 Array Mic Covering Distance 10m
Voltage	Input: 100-240V AC
Power Consumption	(Standby) <0.5W; (Operation) <500W; (Eco) <75W
Front Interface	USB3.0 * 2 lines (Public for both Android & PC); Power ON/OFF keys
Speaker	10W*2 Treble +15W Bass
Bottom Interface	SPDIF: 1; RS232: 1; HDMI OUT: 1; LAN-Port IN: 2; TF Card: 1; AUDIO OUT: 1
Rear Interface	HDMI IN 2.0: 3; USB 2.0: 1; USB 3.0: 2; USB-B 2.0 (touch): 2; HDMI OUT 2.0: 1; USB Type-C 3.1: 1; Public USB-A 3.0: 2; OTG USB-A 2.0: 1; Windows OPS Slot: 80-Pins OPS Slot
Operating System	Windows 7/8/10/11; Android; Mac; Linux; Chrome OS; Android Version: Android 11.0
Video	Support VP9、HEVC/H.265、MPEG1/2、MPEG4、Sorenson H.263、H263
Backlight	Direct Type LED
Accessories	WIFI dongle 1pcs; No Ink Pen 2pcs, Remote Control 1pcs, 1.8m Power Cord 1pcs, 2.0m HDMI Cable 1pcs, 1.5m USB Touch Cable 1pcs; Wall Mount Kit
Other Features	Glass Hardness: Mohs-7 Level; Screen Surface: Anti-Glare glass; Panel Touch Technology: IR Touch; Multi Touch: 20 Points in Windows; Multi Writing 20 Points in Android; Auto-Calibrate: Yes; Anti-Light: Yes; Minimum Object Size: 2mm; Touch Precision: 1 mm (over 90% Area); Support 4K H.265 decoding; Switch On or Off: Yes
Color	Bezel Color: Aluminum Frame Black Color
Active Screen Size	1895.04 * 1065.96(V)
Dimension	1943.497.51166
Weight	65 KG
Warranty	Panel Replacement: 1 Year; Free Service: 3 Year

Description

Artive ATL-11D286 Interactive Flat Panel 86 Inch

Key Features & Benefits:

Massive 86-Inch 4K Ultra HD Display: Expansive 86-inch LED backlit display with true 4K resolution (3840×2160 @60Hz) delivers breathtaking ultra-high-definition visuals for immersive presentations and collaboration.
Powerful Octa-Core Processing: Advanced A73*4 + A53*4 octa-core processor running at 2.28GHz ensures exceptional performance for demanding applications, seamless multitasking, and smooth interactive experiences.
Ample Memory and Storage: 8GB DDR4 RAM enables fluid multitasking while 128GB ROM provides generous storage for apps, media, and collaborative content.
Stunning Color Reproduction: 1.07 billion colors support with 1200:1 contrast ratio ensures vibrant, true-to-life images with exceptional depth and detail across the massive display.
Premium IR Touch Technology: Advanced infrared touch panel with 20-point multi-touch in Windows and 20-point multi-writing in Android enables smooth, responsive collaboration for large groups.
Professional-Grade Camera System: Built-in 48-megapixel wide-angle camera with auto-framing and sound-tracking technology automatically follows speakers and frames participants for premium video conferencing.
Exceptional Audio Performance: Powerful 10W*2 treble speakers plus 15W bass speaker deliver rich, immersive sound; 8-array microphone with 10m coverage ensures crystal-clear voice pickup across large rooms.
Durable Anti-Glare Glass: Mohs-7 level hardness glass with anti-glare surface provides exceptional durability and reduces eye strain in bright environments.
Comprehensive Connectivity: Extensive port selection including 3x HDMI IN 2.0, multiple USB ports (2.0, 3.0, Type-C 3.1, USB-B touch), SPDIF, RS232, LAN, and TF card slot for maximum versatility.
Future-Ready OPS Slot: 80-pin Windows OPS slot enables seamless integration of optional Windows computing module for expanded functionality and dual-system operation.
Dual-Band Wi-Fi 6: Latest Wi-Fi 6 technology with 2.4G+5G dual-band support delivers blazing-fast wireless connectivity for streaming and collaboration.
Universal OS Compatibility: Supports Windows 7/8/10/11, Android 11.0, Mac, Linux, and Chrome OS for flexible deployment across any environment.
Advanced Touch Precision: 1mm touch precision over 90% area with 2mm minimum object size ensures accurate annotation and control; auto-calibrate function maintains optimal performance.
Anti-Light Interference: Advanced anti-light technology ensures reliable touch performance even in challenging lighting conditions with direct sunlight or bright room lighting.
Complete Accessory Package: Includes WiFi dongle, 2x No Ink Pens, remote control, power cord, HDMI cable, USB touch cable, and wall mount kit for immediate deployment.
Extensive Warranty Coverage: 1-year panel replacement and 3-year free service warranty provides long-term peace of mind for enterprise investments.

Ideal For:

Large corporate boardrooms and executive conference centers
University lecture halls and auditoriums
Video conferencing and hybrid workspaces
Command and control centers
Digital signage and large-format advertising
Museum exhibits and cultural institutions
Hotel ballrooms and convention centers
Healthcare facilities and telemedicine
Creative studios and design collaboration
Government and public sector meeting spaces

Summary:
This 86-Inch 4K Interactive LED Display represents the pinnacle of large-format collaboration technology, combining powerful octa-core processing, 8GB RAM, 128GB storage, and professional-grade 48MP auto-framing camera into a comprehensive enterprise solution. With massive 86-inch 4K display quality, Mohs-7 level anti-glare glass, 20-point multi-touch technology, advanced 8-array microphone system with 10m coverage, and powerful 40W audio system with dedicated treble and bass speakers, it delivers unparalleled capabilities for premium interactive environments. The extensive connectivity including Wi-Fi 6, HDMI 2.0, USB Type-C 3.1, and OPS expansion slot, combined with universal OS compatibility and Android 11, ensures seamless integration into any professional setting. Backed by 3-year free service warranty and featuring advanced touch precision, auto-calibration, and anti-light technology, this 86-inch interactive display is the ultimate choice for organizations seeking a flagship, future-ready collaboration hub for the largest and most demanding environments.
