Artive ATL-11D275 Interactive Flat Panel 75 Inch
Exclusive of all taxes
Product Details
Key Features
Display:
75" LED, 3840 x 2160 resolution.
Touch:
IR, 20 touch points.
Multimedia:
Built-in camera, microphone.
Connectivity:
HDMI, USB, LAN, TF card.
Specification
|
Processor |
A73*4 + A53*4
(4 Core+4 Core) 2.28GHz |
|
Memory
Size |
8GB |
|
Memory
Type |
DDR4 |
|
ROM |
128GB |
|
Screen
Size |
75″ LED
Backlight |
|
Image |
Support
JPG/JPEG/BMP/PNG and other image formats |
|
Resolution |
Decoding
Resolution: Support 4K H.265 decoding |
|
Brightness |
350cd/m² |
|
Aspect
Ratio |
16:09 |
|
Response
Time |
<8 ms |
|
Viewing
Angle |
178° |
|
Contrast |
1200:1 (Typ.) |
|
Color
Support |
1.07 Billion
Colors |
|
Graphics |
G52 MP8 |
|
Camera |
Built-in 48
Million Wide-Angle Auto-Framing & Sound-Tracking Camera |
|
Wi-Fi |
Wi-Fi 6
(2.4G+5G) Dual Band |
|
Bluetooth |
5 |
|
Audio |
Support
MPEG1/2, AC3, EAC3(DDP), AAC, HEAAC, WMA, WMA10 pro |
|
Mic |
8 Array Mic
Covering Distance 10m |
|
Voltage |
Input: 100-240V
AC |
|
Power
Consumption |
<0.5W
(Standby); <420W (Operation); <75W (Eco) |
|
Front
Interface |
USB3.0 * 2
lines (Public for both Android & PC); Power ON/OFF keys |
|
Speaker |
10W*2 Treble
+15W Bass |
|
Bottom
Interface |
SPDIF: 1;
RS232: 1; HDMI OUT: 1; LAN-Port IN: 2; TF Card: 1; AUDIO OUT: 1 |
|
Rear
Interface |
HDMI IN 2.0: 3;
USB 2.0: 1; USB 3.0: 2; USB-B 2.0 (touch): 2; HDMI OUT 2.0: 1; USB Type-C
3.1: 1; Public USB-A 3.0: 2; OTG USB-A 2.0: 1; Windows OPS Slot: 80-Pins OPS
Slot |
|
Operating
System |
Android 11.0;
Compliant: Windows; Mac; Linux; Chrome OS |
|
Video |
Support VP9,
HEVC/H.265, MPEG1/2, MPEG4, Sorenson, H.263, H263 |
|
Backlight |
Direct Type LED |
|
Accessories |
WIFI dongle
*1pcs; No Ink Pen * 2pcs, Remote Control *1pcs, 1.8m Power Cord *1pcs, 2.0m
HDMI Cable *1pcs, 1.5m USB Touch Cable *1pcs; Wall Mount Kit |
|
Other
Features |
Glass Hardness:
Mohs-7 Level; Screen Surface: Anti-Glare glass; Touch Technology: IR Touch;
Multi-Touch: 20 Points in Windows; Multi Writing: 20 Points in Android;
Auto-Calibrate: Yes; Anti-Light: Yes; Minimum Object Size 2mm; Touch Precision:
1 mm (over 90% Area); Switch On or Off: Yes |
|
Color |
Aluminum Frame
Black Color |
|
Active
Screen Size |
1649.66 *
927.93(V) |
|
Dimension |
1692.1 *97.5*1021.9 |
|
Weight |
51 KG |
|
Warranty |
Panel
Replacement: 1 Year; Free Service: 3 Year |
Description
Artive ATL-11D275 Interactive Flat Panel 75
Inch
Key Features & Benefits:
- Powerful
Octa-Core Processing: Advanced
A73*4 + A53*4 octa-core processor running at 2.28GHz delivers exceptional
performance for demanding applications, multitasking, and smooth
interactive experiences.
- Ample
Memory and Storage: 8GB
DDR4 RAM ensures seamless multitasking while 128GB ROM provides generous storage
for apps, media, and files.
- Massive
75-Inch 4K Display: Expansive
75-inch LED backlit display with 4K H.265 decoding capability delivers
breathtaking ultra-high-definition visuals with 350cd/m² brightness and
178° wide viewing angle.
- Stunning
Color Reproduction: 1.07
billion colors support and 1200:1 contrast ratio ensure vibrant,
true-to-life images with exceptional depth and detail.
- Premium
Touch Technology: IR
Touch technology with 20-point multi-touch in Windows and 20-point
multi-writing in Android enables smooth, responsive collaboration.
Auto-calibrate function and 1mm touch precision over 90% area ensure
accurate interaction.
- Professional-Grade
Camera System: Built-in
48-megapixel wide-angle camera with auto-framing and sound-tracking
technology enables premium video conferencing and content capture.
- Durable
Anti-Glare Glass: Mohs-7
level hardness glass with anti-glare surface provides exceptional
durability and reduces eye strain in bright environments.
- Advanced
Audio System: 10W*2
treble speakers plus 15W bass speaker deliver rich, immersive sound;
8-array microphone with 10m coverage distance ensures crystal-clear voice
pickup.
- Comprehensive
Connectivity: Extensive
port selection including 3x HDMI IN 2.0, multiple USB ports (2.0, 3.0,
Type-C 3.1, USB-B touch), SPDIF, RS232, LAN, and TF card slot for maximum
versatility.
- Future-Ready
OPS Slot: 80-pin
Windows OPS slot enables seamless integration of optional Windows
computing module for expanded functionality.
- Dual-Band
Wi-Fi 6: Latest
Wi-Fi 6 technology with 2.4G+5G dual-band support delivers blazing-fast
wireless connectivity.
- Bluetooth
5.0: Latest Bluetooth
version ensures reliable connections to wireless peripherals and
accessories.
- Android
11 Operating System: Modern
Android 11 platform with cross-platform compatibility for Windows, Mac,
Linux, and Chrome OS ensures flexible deployment options.
- Anti-Light
Interference: Advanced
anti-light technology ensures reliable touch performance even in
challenging lighting conditions.
- Comprehensive
Video Format Support: Wide
range of supported formats including VP9, HEVC/H.265, MPEG1/2, MPEG4, and
more for versatile media playback.
- Complete
Accessory Package: Includes
WiFi dongle, 2x No Ink Pens, remote control, power cord, HDMI cable, USB
touch cable, and wall mount kit for immediate deployment.
- Extensive
Warranty Coverage: 1-year
panel replacement and 3-year free service warranty provides long-term
peace of mind.
Ideal For:
- Corporate boardrooms and executive conference
rooms
- Educational institutions and smart classrooms
- Video conferencing and hybrid workspaces
- Digital signage and large-format advertising
- Interactive kiosks and public information
displays
- Training facilities and presentation venues
- Control rooms and command centers
- Hotel ballrooms and event spaces
- Healthcare facilities and telemedicine
- Creative studios and design collaboration
Summary:
This 75-Inch 4K Interactive LED Display combines powerful octa-core processing,
8GB RAM, 128GB storage, and professional-grade 48MP auto-framing camera into a
comprehensive large-format collaboration solution. With expansive 75-inch 4K
display quality, Mohs-7 level anti-glare glass, 20-point multi-touch
technology, advanced 8-array microphone system with 10m coverage, and rich audio
with dedicated treble and bass speakers, it delivers unparalleled versatility
for premium interactive environments. The extensive connectivity including
Wi-Fi 6, HDMI 2.0, USB Type-C 3.1, and OPS expansion slot, combined with
Android 11 and cross-platform compatibility, ensures seamless integration into
any professional setting. Backed by 3-year free service warranty and featuring
advanced touch precision, auto-calibration, and anti-light technology, this
75-inch interactive display is the ultimate choice for organizations seeking a
premium, future-ready collaboration hub
