Dahua NVR5864-EI 64-Channel Network Video Recorder

Genuine Product Fast Delivery Easy Returns

SPECIFICATION

Feature	Specification
Model	Dahua NVR5864-EI
Series	WizSense 5-EI Series
Type	Network Video Recorder (NVR)
Main Processor	Industrial-grade processor
Operating System	Embedded Linux
Video Channels	64 Channels
Incoming Bandwidth	AI disabled: 384 Mbps, AI enabled: 200 Mbps
Recording Bandwidth	AI disabled: 384 Mbps, AI enabled: 200 Mbps
Outgoing Bandwidth	AI disabled: 384 Mbps, AI enabled: 200 Mbps
Decoding Capability (AI disabled)	2-ch 32MP@25fps, 2-ch 24MP@25fps, 4-ch 16MP@30fps, 5-ch 12MP@30fps, 8-ch 8MP@30fps, 12-ch 5MP@30fps, 16-ch 4MP@30fps, 32-ch 1080p@30fps
Decoding Capability (AI enabled)	1-ch 32MP@25fps, 1-ch 24MP@25fps, 2-ch 16MP@30fps, 4-ch 12MP@30fps, 6-ch 8MP@30fps, 8-ch 5MP@30fps, 12-ch 4MP@30fps, 24-ch 1080p@30fps
Video Compression	Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
Audio Compression	G.711a, G.711u, PCM, G726
HDD Interface	8 SATA ports, each up to 20TB
RAID Support	RAID 0/1/5/6/10
eSATA	1
Video Output	2 HDMI, 2 VGA (HDMI up to 4K resolution)
Audio Input	1-channel RCA
Audio Output	2-channel RCA
Alarm Input	16 channels
Alarm Output	8 channels
Network Port	2 x RJ-45 10/100/1000 Mbps
USB Port	4 (2 front USB 2.0, 2 rear USB 3.0)
RS-232	1
RS-485	2
AI by Recorder	Face detection/recognition (2-ch), Perimeter protection (4-ch), SMD Plus (8-ch)
AI by Camera	Face detection/recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, people counting, crowd distribution, vehicle density
Face Database Capacity	Up to 20 face databases, 20,000 face images, 2.5GB capacity
AcuPick Support	Max 16-channel (AI by Camera + Recorder)
Multi-channel Playback	Up to 16 channels
Multi-screen Display	Main: 1/4/8/9/16/25/36/64, Sub: 1/4/8/9/16
Third-party Camera Support	ONVIF, Panasonic, Sony, Axis, Arecont, Pelco, Canon, Samsung
Mobile Access	iOS, Android
Power Supply	100–240 VAC, 50-60 Hz
Power Consumption	≤ 13 W (without HDD)
Net Weight	6.4 kg
Dimensions (W×D×H)	439.9 × 457.9 × 89.0 mm
Operating Temperature	–10 °C to +55 °C
Operating Humidity	10%–93% (RH)
Installation	Rack or desktop
Warranty	1 Year

DESCRIPTION

Dahua NVR5864-EI 64-Channel Network Video Recorder

The Dahua NVR5864-EI is a 64-channel WizSense Series Network Video Recorder designed for professional IP video surveillance applications. Powered by an industrial-grade embedded processor and Linux operating system, this NVR delivers high-performance recording, decoding, and AI analytics for medium to large-scale security installations.

The recorder supports up to 64 IP camera channels with 384 Mbps incoming/recording/outgoing bandwidth when AI is disabled, and 200 Mbps when AI features are enabled. Decoding capability reaches 32 channels of 1080p@30fps simultaneously, with support for camera resolutions up to 32MP. Video compression includes Smart H.265+, H.265, Smart H.264+, and H.264 for efficient storage utilization.

AI Capabilities: The NVR5864-EI features comprehensive AI functionality both from the recorder and connected cameras. AI by recorder includes 2-channel face detection and recognition, 4-channel perimeter protection with 10 IVS rules per channel, and 8-channel SMD Plus (secondary motion detection) for human and vehicle filtering. AI by camera supports face detection/recognition, perimeter protection, SMD Plus, video metadata (human, motor vehicles, non-motor vehicles), ANPR (automatic number plate recognition), stereo analysis, heat map generation, people counting, crowd distribution, and vehicle density analysis. The face database can store up to 20,000 face images across 20 databases with 2.5GB capacity.

Storage and Reliability: The NVR features 8 SATA ports supporting HDDs up to 20TB each, with RAID 0/1/5/6/10 support for data redundancy and protection. Additional storage options include one eSATA port. The system supports N+M cluster for high availability and iSCSI for network storage expansion.

Connectivity and Output: Dual Gigabit Ethernet ports provide network connectivity with multi-address mode, load balance, and fault tolerance options. Video output includes two HDMI ports (supporting 4K resolution) and two VGA ports for heterogeneous or simultaneous display. Multi-screen display supports up to 64 divisions on main screen and 16 on sub screen. Audio features include 1-channel RCA input and 2-channel RCA output.

Compatibility and Integration: The recorder supports ONVIF Profile T/S/G, CGI, and SDK for broad interoperability with third-party cameras from Panasonic, Sony, Axis, Pelco, Canon, Samsung, and others. Mobile access is available through iOS and Android apps. Web browsers supported include Chrome, IE, Safari, Edge, and Firefox.

Alarm and Event Management: With 16 alarm inputs and 8 alarm outputs, the NVR integrates with external sensors and devices. Intelligent alarms cover face detection, perimeter protection, video metadata, SMD Plus, stereo analysis, crowd distribution, people counting, ANPR, vehicle density, and heat map events. Alarm linkages include recording, snapshot, local alarm output, IPC external alarm, access controller, audio, buzzer, log, preset, and email notifications.

The Dahua NVR5864-EI delivers enterprise-grade recording and AI analytics in a 2U form factor suitable for rack or desktop installation, backed by 1-year warranty for reliable long-term operation in professional security environments.
