Bosch Plena PLE-1ME240 240Watts 2 Zone Mixer Amplifier

Genuine Product Fast Delivery Easy Returns

Key Features

Two-zone Mixing for Flexible Audio Control: The Bosch Plena PLE-1ME240 features a 2-zone mixer amplifier, allowing you to control audio levels and mixing for two separate areas.

High-Power Output for Clear Audio: With a total power output of 240 W, this mixer amplifier delivers clear and powerful audio to your audience.

Multiple Input Options for Versatility: The PLE-1ME240 accepts mic/line inputs, music inputs, and telephone/call station inputs, making it suitable for a variety of applications.

Efficient Cooling for Reliable Operation: The passive/natural convection cooling system ensures reliable operation and prolongs the lifespan of the amplifier.

Compact Design for Easy Installation: Measuring 100 × 430 × 270 mm (2U), this mixer amplifier is designed for easy installation in a variety of settings.

Impedance Options for Flexibility: The PLE-1ME240 features 8 Ω / 70 V / 100 V outputs, allowing you to choose the impedance that suits your specific needs.

High Sensitivity for Clear Audio: With a sensitivity of Mic ~1 mV; Line ~1 V; Music ~300 mV, this mixer amplifier delivers clear and powerful audio to your audience.

Dual Power Supply for Redundancy: The 230 V AC & 24 V DC (backup) power supply ensures continuous operation even in the event of a power failure.

Low Total Harmonic Distortion for Clear Audio: The PLE-1ME240 features a Total Harmonic Distortion (THD) of <1 % @ rated power, ensuring clear and distortion-free audio.

Multiple Mic/Line Inputs for Versatility: The mixer amplifier accepts 6 mic/line balanced inputs, making it suitable for a variety of applications.

High Signal-to-Noise Ratio for Clear Audio: The PLE-1ME240 features a signal-to-noise ratio of Mic/Line >63 dB / Aux >75 dB, ensuring clear and distortion-free audio.

Reliable Operation for Prolonged Lifespan: The passive/natural convection cooling system and efficient design ensure reliable operation and prolong the lifespan of the amplifier.

Specification

Amplifier Type	Integrated 2-zone mixer amplifier
Connectivity	Mic/line inputs, music inputs, telephone/call station inputs
Cooling	Passive / natural convection
Interface	Balanced mic/line terminals, music inputs, zone outputs
Channels	2 zone mixer amplifier (single output, 240 W)
Weight	12.5 kg
Dimensions	100 × 430 × 270 mm (2U)
Impedance	8 Ω / 70 V / 100 V outputs
Sensitivity	Mic ~1 mV; Line ~1 V; Music ~300 mV
Power Supply	230 V AC & 24 V DC (backup)
Power Output	240 W total
Signal to Noise Ratio	Mic/Line >63 dB / Aux >75 dB
Total Harmonic Distortion (THD)	<1 % @ rated power
Microphone	6 mic/line balanced inputs

Description

Bosch Plena PLE-1ME240 240Watts 2 Zone Mixer Amplifier

Key Features & Benefits:

Two-zone Mixing for Flexible Audio Control: The Bosch Plena PLE-1ME240 features a 2-zone mixer amplifier, allowing you to control audio levels and mixing for two separate areas.
High-Power Output for Clear Audio: With a total power output of 240 W, this mixer amplifier delivers clear and powerful audio to your audience.
Multiple Input Options for Versatility: The PLE-1ME240 accepts mic/line inputs, music inputs, and telephone/call station inputs, making it suitable for a variety of applications.
Efficient Cooling for Reliable Operation: The passive/natural convection cooling system ensures reliable operation and prolongs the lifespan of the amplifier.
Compact Design for Easy Installation: Measuring 100 × 430 × 270 mm (2U), this mixer amplifier is designed for easy installation in a variety of settings.
Impedance Options for Flexibility: The PLE-1ME240 features 8 Ω / 70 V / 100 V outputs, allowing you to choose the impedance that suits your specific needs.
High Sensitivity for Clear Audio: With a sensitivity of Mic ~1 mV; Line ~1 V; Music ~300 mV, this mixer amplifier delivers clear and powerful audio to your audience.
Dual Power Supply for Redundancy: The 230 V AC & 24 V DC (backup) power supply ensures continuous operation even in the event of a power failure.
Low Total Harmonic Distortion for Clear Audio: The PLE-1ME240 features a Total Harmonic Distortion (THD) of <1 % @ rated power, ensuring clear and distortion-free audio.
Multiple Mic/Line Inputs for Versatility: The mixer amplifier accepts 6 mic/line balanced inputs, making it suitable for a variety of applications.
High Signal-to-Noise Ratio for Clear Audio: The PLE-1ME240 features a signal-to-noise ratio of Mic/Line >63 dB / Aux >75 dB, ensuring clear and distortion-free audio.
Reliable Operation for Prolonged Lifespan: The passive/natural convection cooling system and efficient design ensure reliable operation and prolong the lifespan of the amplifier.

Ideal For:

Conference rooms
Theaters
Meeting rooms
Classrooms
Public address systems
Live events
Music performances

Summary:

The Bosch Plena PLE-1ME240 is a high-power 2-zone mixer amplifier suitable for a variety of applications, including conference rooms, theaters, and public address systems. With its high-power output, efficient cooling system, and multiple input options, this mixer amplifier delivers clear and powerful audio to your audience. Available at Revolution Technology BD, this product is ideal for anyone looking for a reliable and versatile audio solution.
