Secure Saral Single Phase Net Meter
Contact us for pricing
Product Details
Key Features
High Accuracy: Class 1.0 accuracy ensures precise energy measurement for billing and monitoring.
Broad Current Range: Supports 5–30A, 10–60A, and 10–100A ranges, fitting diverse residential and small commercial loads.
Dual Energy Capture: Measures both active and apparent energy, providing comprehensive power quality data.
Bidirectional Energy Flow: Tracks forward, import, and export energy, ideal for net‑metering installations.
Robust Surge Protection: Withstands surges up to 10kV, protecting the meter in unstable grid conditions.
IP54 Sealed Enclosure: Dust‑tight and splash‑proof design suitable for indoor and semi‑outdoor deployments.
Multi‑Tariff Capability: Up to 8 rate registers and 8 time zones enable complex tariff structures and time‑of‑use billing.
Extensive Data Logging: Load survey over 150 days, 12 billing periods, and 300 tamper events stored for detailed analysis.
Flexible Communication: Optical port (IEC 62056-21) plus optional BLE, RS232, and Micro‑USB for easy integration.
Compact and Light: Dimensions of 95×130×60 mm and weight of 0.3 kg allow easy installation in tight spaces.
Product Model | Saral |
Product Type | Single Phase Energy / Net Meter |
Connection | Direct Connected |
Wiring | Single Phase, 2-Wire |
Nominal Voltage | 230V / 240V |
Current Ratings | 5–30A, 10–60A, 10–100A |
Accuracy Class | Class 1.0 |
Frequency | 50Hz / 60Hz |
Energy Measurement | Active Energy & Apparent Energy |
Energy Direction | Forward, Import & Export |
Surge Withstand | Up to 10kV |
IP Rating | IP54 |
Operating Temperature | -20°C to +60°C |
Humidity | Up to 95% non-condensing |
Meter Constants | 6400 / 3200 / 1280 imp/kWh |
Communication | Optical Port, IEC 62056-21 |
Optional Communication | BLE / RS232 Micro-USB |
Multi-Tariff | Up to 8 Rate Registers & 8 Time Zones |
Load Survey | More than 150 days |
Historical Billing | 12 Billing Periods |
Tamper Event Memory | Up to 300 timestamped events |
Dimensions | Approx. 95 × 130 × 60 mm |
Weight | Approx. 0.3 kg |
Enclosure | Sealed Engineering Plastic |
Standards | IS 13779, IEC 62052-11, IEC 62053-21, IS 15959 |
Description
Secure Saral Single Phase Net Meter
Key Features & Benefits:
- High Accuracy: Class 1.0 accuracy ensures precise energy measurement for billing and monitoring.
- Broad Current Range: Supports 5–30A, 10–60A, and 10–100A ranges, fitting diverse residential and small commercial loads.
- Dual Energy Capture: Measures both active and apparent energy, providing comprehensive power quality data.
- Bidirectional Energy Flow: Tracks forward, import, and export energy, ideal for net‑metering installations.
- Robust Surge Protection: Withstands surges up to 10kV, protecting the meter in unstable grid conditions.
- IP54 Sealed Enclosure: Dust‑tight and splash‑proof design suitable for indoor and semi‑outdoor deployments.
- Multi‑Tariff Capability: Up to 8 rate registers and 8 time zones enable complex tariff structures and time‑of‑use billing.
- Extensive Data Logging: Load survey over 150 days, 12 billing periods, and 300 tamper events stored for detailed analysis.
- Flexible Communication: Optical port (IEC 62056-21) plus optional BLE, RS232, and Micro‑USB for easy integration.
- Compact and Light: Dimensions of 95×130×60 mm and weight of 0.3 kg allow easy installation in tight spaces.
Ideal For:
- Residential homeowners with solar PV systems
- Small commercial shops needing accurate billing
- Utility companies deploying net‑metering programs
- Energy auditors requiring detailed load surveys
- Property managers monitoring multiple tenants
- Industrial micro‑plants with variable tariffs
- DIY enthusiasts installing smart home energy dashboards
Summary:
The Secure Saral Single Phase Net Meter delivers Class 1.0 accuracy across a wide 5–100 A current range, supporting both active and apparent energy measurement with bidirectional flow tracking. Its IP54 sealed housing, 10 kV surge protection, and multi‑tariff capability make it ideal for residential, commercial, and net‑metering applications. With extensive data logging, flexible communication options, and compliance to international standards, it offers reliable performance for modern energy management. Available now at Revolution Technology BD.
