GearUP 8-Way DC PV Combiner Box with MCB, Fuse & SPD

Genuine Product Fast Delivery Easy Returns

Out Of Stock

Key Features

Robust 8-String Handling: Handles up to eight DC PV strings with dedicated 15A/1000V fuses, ensuring each string is individually protected.

Powerful Main Protection: 125A/1000V DC 2-pole MCB isolates the entire array, providing primary overcurrent and short-circuit protection.

Lightning-Grade SPD: 1000V DC, 20-40kA surge arrester diverts lightning-induced spikes safely to ground.

Weatherproof Design: IP65 enclosure made of UV-resistant polycarbonate protects against dust and water jets in Bangladesh’s climate.

Plug-and-Play Connectivity: MC4 compatible terminals simplify installation and maintenance for solar panels and inverters.

Quick Health Status: Visual SPD indicator shows green for good, red for failed, enabling instant system checks.

Easy Wall Mounting: Pre-drilled holes and compact design allow technicians to install quickly on any wall.

Compliance & Safety: CE and RoHS-equivalent components guarantee international safety and quality standards.

Corrosion-Resistant Build: High-grade materials resist humidity-induced corrosion, extending product life.

Comprehensive Grounding: Built-in grounding busbar ensures proper earthing for all connected strings.

Specification

8-Way Input Configuration	Accommodates up to eight individual DC PV strings, suitable for medium to large-scale solar installations.
Integrated DC Main Circuit Breaker (MCB)	125A, 1000V DC MCB provides primary overcurrent and short-circuit protection for the entire combined array, allowing for safe system disconnection.
Individual String Fuses	Each of the eight input strings is protected by a dedicated 15A, 1000V DC fuse, isolating any faulty string to prevent cascading failures and simplify troubleshooting.
High-Performance Surge Protection Device (SPD)	1000V DC, 20-40kA SPD guards the system against dangerous voltage spikes caused by lightning or other transient events, diverting excess energy safely to the ground.
IP65 Waterproof and Dustproof Enclosure	Constructed from high-quality, UV-resistant polycarbonate (PC), the robust enclosure ensures complete protection against dust ingress and powerful water jets, making it perfectly suited for outdoor installation in any weather condition prevalent in Bangladesh.
MC4 Compatible Terminals	Features industry-standard MC4 input and output connectors for secure, reliable, and easy plug-and-play connections with your solar panels and inverter.
Visual Fault Indicators	The SPD includes a visual status indicator (green for good, red for failed) for quick and easy health checks.
Easy Installation	Designed for straightforward wall mounting with pre-drilled holes, making installation efficient for technicians.
Safety Standards Compliant	Manufactured to meet rigorous international safety and quality standards (e.g., CE, RoHS equivalent for components), ensuring dependable operation.
Corrosion Resistance	The high-grade enclosure material and internal components are selected for their resistance to corrosion, ensuring longevity in humid environments common in Bangladesh.
DC Fuses	8 sets of 15A/1000V DC fuses, specifically designed for PV applications.
DC Main Circuit Breaker	1 x 125A/1000V DC 2-pole MCB for main circuit protection and isolation.
DC Surge Protection Device (SPD)	1 x 1000V DC, 20-40kA, Type 2 surge arrester with visual status indicator.
Input Connectors	8 pairs of MC4 compatible input terminals.
Output Connectors	1 pair of MC4 compatible output terminals.
Grounding Terminal	Pre-installed grounding busbar for proper earthing.

Description

GearUP 8-Way DC PV Combiner Box with MCB, Fuse & SPD

Key Features & Benefits:

Robust 8-String Handling: Handles up to eight DC PV strings with dedicated 15A/1000V fuses, ensuring each string is individually protected.
Powerful Main Protection: 125A/1000V DC 2-pole MCB isolates the entire array, providing primary overcurrent and short-circuit protection.
Lightning-Grade SPD: 1000V DC, 20-40kA surge arrester diverts lightning-induced spikes safely to ground.
Weatherproof Design: IP65 enclosure made of UV-resistant polycarbonate protects against dust and water jets in Bangladesh’s climate.
Plug-and-Play Connectivity: MC4 compatible terminals simplify installation and maintenance for solar panels and inverters.
Quick Health Status: Visual SPD indicator shows green for good, red for failed, enabling instant system checks.
Easy Wall Mounting: Pre-drilled holes and compact design allow technicians to install quickly on any wall.
Compliance & Safety: CE and RoHS-equivalent components guarantee international safety and quality standards.
Corrosion-Resistant Build: High-grade materials resist humidity-induced corrosion, extending product life.
Comprehensive Grounding: Built-in grounding busbar ensures proper earthing for all connected strings.

Ideal For:

Medium to large-scale solar installations
Residential solar owners seeking robust combiner solutions
Industrial PV plant operators
Renewable energy consultants designing PV systems
Government and municipal solar projects
Solar installation technicians
Off-grid solar system integrators

Summary:

The GearUP 8-Way DC PV Combiner Box delivers reliable performance with 8 dedicated 15A/1000V fuses, a 125A/1000V main MCB, and a 1000V/20-40kA SPD. Its IP65 polycarbonate enclosure, MC4 connectors, and visual fault indicators make it ideal for Bangladesh’s harsh outdoor conditions. Designed for easy wall mounting and full safety compliance, it is a top choice for residential, commercial, and industrial solar projects available at Revolution Technology BD.
