BenQ RE8605A 86 Inch 4K UHD Education Interactive Flat Panel Display

Brand

BenQ

Model

RE8605A

Country of Origin

Taiwan

Eligibility of Brand

The brand must have a minimum of 10 years of experience in manufacturing Interactive Flat Panel (IFP) business.

Item

86-inch Interactive Flat Panel Display

Display Size (Diagonal)

Minimum 86 inches

Display Resolution

Minimum 4K UHD (3840 × 2160) or higher

Display Type

Anti-glare display with scratch-resistant tempered/toughened protective glass (minimum 3 mm thickness).

Display Technology

Zero Bonding and DLED

Glass

Germ-resistant technology, antimicrobial protective screen, Zero Bonding, Anti-glare

Glass Hardness

Minimum 9H tempered or Higher

Germ-resistant

Screen

Contrast Ratio

1200:1 or higher

Contrast Ratio (dynamic)

50,000:1 or higher

Display Brightness

Minimum 450 cd/m2 or higher

Colour Depth

1.07 billion colours or higher

Panel Lifespan

50000 Hours or higher

Touch Interface

Touch Sensitive as well as Pen Driven

Touch Technology

Infrared Optical

Number of Touch Points

40 Touch Points for Windows; 40 Touch Points for Android

Touch Response Time

≤5 ms

Operating System

Android 16 or higher with Google EDLA Certified for quoted model/series of panel that should be verifiable online.

CPU

Octa-Core or Higher

Number of Cores

8 Core or higher

GPU

Arm Mali-G52 MC3

NPU

6 TOPS or higher

RAM

Minimum 8 GB

Storage

Minimum 128 GB

Camera

1080P FHD, 92° wide field of view, Omnidirectional mics × 2Pickup range: Up to 5m (16 ft), Echo cancellation, Privacy cover, Low distortion, Lens type-Glass, Adjusts to lighting conditions, Lense Type-Glass, USB-Plug and play

Microphone

Min 5-microphone array (range: up to 5 m | 16ft) through USB camera

Built-in Speaker

50 Watts (25W x 2 speakers) or higher

Connectivity & Interfaces

3 x HDMI In 2.01 x HDMI Out 2.03 x USB-A 3.0 (High speed data transfer & power supply)1 x USB-A 2.02 x USB-B Touch1 x USB Type-C 3.0 (5-in-1, 5Gbps data transfer, video, audio, touch, 65W PD) 1 x Mic In (3.5 mm)1 x Earphone (3.5 mm)1 x RS2321 x SPDIF Out (optical)1 x OPS Slot1 x LAN In/Out (RJ45) 1 x IR Receiver1 x Light Sensor

Wi-Fi

Yes, with compatibility of both 2.4GHZ and 5GHZ

Bluetooth

Yes, V5.0 or above

HDMI & Touch Cable

3 meter each

Certification

CE, FCC, RoHS, ISO 9001, ISO 14001, ISO 45001, Energy Star, TUV Certification (certificate shall be verifiable online), SIAA, ADA – CASA Certification (germ resistance), IP5X Certificate (dust resistance).

Accessories

Wall Mount with 8 Fasteners, Remote Control, Stylus (2 Nos, two-sided passive stylus), Power Cable, HDMI Cable, USB Cable

Software features

The IFP shall include same-brand, OEM-developed MDM software for centralized management and real-time monitoring of unlimited devices, including power status, activity reporting, and user profile management. The software shall be provided with lifetime access; subscription-based models are not acceptable.The interactive display shall support multi-touch and multi-user writing, centralized text/image/video broadcasting via OEM MDM, native English and Bangla handwriting recognition, screen recording, finger-touch operation, snapshot capture from running videos, and real-time annotation with zero-lag writing performance.The interactive display shall include built-in software to view images (JPG, JPEG, PNG, GIF, etc.), documents (PDF, MS Word, Excel, PowerPoint), play audio (MP3, M4A, etc.), and video files (MP4, MPEG, etc.), supporting all major file formats.The IFP shall include an inbuilt interactive whiteboard supporting pen, highlighter, dual pen, eraser, color palette, customizable backgrounds, templates, and a minimum of 900 pages. It shall support handwriting-to-text conversion, copy/paste, OCR, text-to-speech, handwriting and shape recognition, AI-assisted tools, mathematical formula recognition, and translation into 20 or more languages. The software shall include educational tools such as ruler, protractor, set square, compass, stopwatch, countdown timer, calculator, scoreboard, random number generator, spin wheel, mind maps, 2D/3D shapes, image libraries, sticky notes and Quiz. It shall support insertion of Microsoft Office files, PDF, images, audio, video, web links, YouTube links, and document camera input. The software shall provide whiteboard recording, cloud collaboration with remote annotation, QR code sharing, and be available for Android, Windows, and Web platforms.The interactive display shall support wireless screen sharing and reverse casting for Windows laptops/desktops and Android devices through the OEM's proprietary casting software. It shall include an always-accessible floating toolbar, built-in Google Play Store and OEM App Store, integrated cloud storage access (Google Drive, OneDrive, etc.), and support for Google Slides integration.

Remote Device Management Software (Same Brand)

Pre-installed by default on the IFP, providing centralized remote management of all networked displays. Features include a real-time monitoring dashboard, remote display control, user policy enforcement, app blocking and whitelisting, configurable user settings, multiple authentication options, guest login enable/disable, COPPA compliance, and lifetime access. The software must be developed by the same OEM.

Remote Broadcasting Software (Same Brand)

Pre-installed by default on the IFP for centralized broadcasting of scheduled messages and instant alerts to all connected displays. Shall support PPT, PDF, video, YouTube, image, and text-based announcements. Software must be developed by the same OEM and provided with lifetime access.

Wireless Screen Sharing Software (Same Brand)

The IFP shall include OEM-developed wireless screen sharing software supporting simultaneous sharing of at least 9 devices from Android, iOS, Windows, and macOS platforms. The software shall support reverse casting, webcasting, annotation, AI Lens, and BYOM (Bring Your Own Meeting) for direct access to the IFP's camera and microphone during video conferencing. It shall also include annotation tools such as pen, eraser, and screen capture, with lifetime access.

Account management Software (Same Brand)

The IFP shall include pre-installed, OEM-developed account management software enabling secure access to cloud storage services (e.g., Google Drive, OneDrive, Dropbox, and Nextcloud) with Two-Factor Authentication (2FA). It shall support global user settings, QR code login, credential-based login, and Single Sign-On (SSO), with lifetime access.

Data Security

The IFP shall support USB port lock, screen lock, application lock, and Single Sign-On (SSO) to prevent unauthorized access. It shall support application control through built-in or third-party software and comply with recognized data security and privacy standards, including the European Union’s General Data Protection Regulation (GDPR), the California Consumer Privacy Act (CCPA), the UK’s Product Security and Telecommunications Infrastructure (PSTI), the Cloud Application Security Assessment (CASA), the Children’s Online Privacy Protection Act (COPPA), and ISO/IEC 27001 security standards.

Power Consumption (Typical)

110W or Lower

Brand's Authorized Service Center

The bidder shall submit the Standard Operating Procedure (SOP) of the manufacturer's authorized service center. The manufacturer shall have a minimum of 20 authorized service centers across Bangladesh.

Required Documents

Manufacturer Authorization Letter Must be submittedManufacturer Warranty Certificate Must be submittedProduction Capacity Certificate Must be submittedDeclaration for Spare Parts and Services Must be submitted

Warranty

Minimum 3 Years On-site Warranty
